HAMMEL VB 450
HAMMEL VB 450 - Image 2
HAMMEL VB 450 - Image 3
HAMMEL VB 450 - Image 4

HAMMEL VB 450

Primary Shredding Machine

HAMMEL VB 450 DK / D / E

Advantages

  • 3 PART HOPPER EXTENSION
  • MULTI-FUNCTIONAL SHREDDING SHAFTS
  • USER-FRIENDLY USER CONTROLS
GET A QUOTE
Category: Brand:

Description

The HAMMEL VB 450 D, DK and E are compact, robust primary shredders built around the proven twin slow-speed shaft principle, delivering efficient, low noise and low-wear processing across a wide range of materials including wood waste, pallets, green waste, and domestic or commercial waste.

Specifications:

VB 450 DKVB 450 DVB 450 ETHROUGHPUT
DRIVE
ENGINE 137 PS (101 kW) Cummins F3.8
MAX TORQUE 80000 Nm
ENGINE SPEED 2200 RPM
FUEL CAPACITY 160 L
DISCHARGE BELT
HEIGHT 2800 mm / BEI 33°
WIDTH 800 mm
SHAFTS
WORKING LENGTH 1212 mm
TOTAL LENGTH 1540 mm
DIAMETER 450 mm
ROTATION 8 – 32 (min-1)
HOPPER
VOLUME 2 m³
MAIN / TILTING Surface for long materials
DIMENSIONS
WORKING LxBxH: 7,3 x 1,7 x 3,6
TRANSPORT LxBxH: 5,9 x 1,7 x 2,4
WEIGHT 9 TONS + 1 TON (magnet)
DRIVE
ENGINE 144 PS (106kW) CAT C4.4
MAX TORQUE 80000 Nm
ENGINE SPEED 2100 RPM
FUEL CAPACITY 180 L
DISCHARGE BELT
HEIGHT 2500 mm / BEI 33°
WIDTH 800 mm
SHAFTS
WORKING LENGTH 1212 mm
TOTAL LENGTH 1540 mm
DIAMETER 450 mm
ROTATION 8 – 32 (min-1)
HOPPER
VOLUME 2 m³
MAIN / TILTING Surface for long materials
DIMENSIONS
WORKING LxBxH: 7,3 x 1,7 x 3,6
TRANSPORT LxBxH: 6,1 x 1,9 x 2,3
WEIGHT 8 TONS + 1 TON (magnet)
DRIVE
ENGINE 110 KW
MAX TORQUE 80000 Nm
ENGINE SPEED 3000 RPM
FUEL CAPACITY n/a
DISCHARGE BELT
HEIGHT 2700 mm / BEI 33°
WIDTH 800 mm
SHAFTS
WORKING LENGTH 1212 mm
TOTAL LENGTH 1540 mm
DIAMETER 450 mm
ROTATION 9 – 46 (min-1)
HOPPER
VOLUME 2 m³
MAIN / TILTING Surface for long materials
DIMENSIONS
WORKING LxBxH: 8 x 1,9 x 3,7
TRANSPORT LxBxH: 6,6 x 1,9 x 2,3
WEIGHT 9 TONS + 1 TON (magnet)
MATERIAL TONNES PER HOUR
WASTE WOOD 12
PALLETS 10
CABLE DRUMS 6
RAILWAY SLEEPERS n/a
ROOT STEMS 8
GREEN WASTE 6

Enquire about this machine…
